FROND
Swooping lamp that can be suspended at different angles & heights. We recommend an ambient bulb for a gentle ambient warmth or A60 for larger areas.
FROND
horizontal pendant lamp
3600 ZAR
All prices ex VAT / delivery
FINISH
OPTIONS
SUSPENSION OPTIONS
ONE
TWO
THREE
FOUR
FIVE
ONE. Pendant hanging horizontal from a single ceiling canopy (Table size: 1200 x 2100 x 750mm)
TWO Pendants hanging at angles from individual ceiling canopies (Table size: 1200 x 2400 x 750mm)
THREE Pendants hanging at angles from individual ceiling canopies (Table size: 3000 x 1200 x 750mm)
FOUR & FIVE Ceiling Height: 4100mm
FROND SIZING & SPECIFICATIONS
A Ceiling Canopy 127Ø x 27mm | B Tension Wire 1500mm | C electric cabling 1500mm
HOW TO CUSTOMISE
THE FROND PENDANT
SPECIFICATIONS
FROND SIZING: 150 x 1400 x 165mm H
FROND WEIGHT: 1.8kg
MATERIAL: mild steel
ELECTRIC CABLING: 1500mm supplied
TENSION WIRE:
2 lengths of 2mm Swagged Head SS tension wire
HOOKS: No10 and No6 powder-coated hooks
PART SPECIFICATIONS
ELECTRIC CABLING
2 core, 0.75mm2, 220-240V
double PVC insulation,
with or without colour braid
LAMP HOLDER
TYPE: E27 / Plain casing
Casing: PET GF, T1210
Nominal rating: 4/250
Push in twin terminals: 0.5-2.5mm2
TENSION WIRE SPECIFICATIONS
2mm JAKOB TENSION WIRE ROPE with swaged radius head end stop
ASI 316 STAINLESS STEEL 6 x 7 + WC
RATED 2,4kN minimum breaking strength
SUPPLIED WITH 2mm aluminium ferrules
